Automatic AC/DC Voltage Testing: Automatically detects AC and DC voltages, making it easy to test electrical systems without manually adjusting settings.
Wide Current Range: Capable of testing currents up to 10A, suitable for various electrical tasks.
Digital Display: Provides clear, easy-to-read measurements, ensuring accurate results for any user.
Data Retention: Retains readings for further reference, ideal for tracking electrical signals.
High Voltage Testing: Can test up to 600V, making it suitable for high-voltage applications.
Current, Ohm, Ammeter, and Detector Functions: Useful for measuring resistance, diagnosing circuits, and other common electrical tasks.
Compact and Portable: Small enough to be used in different environments, including workshops, DIY projects, or home applications.
Specifications:
DC Voltage:
200mV: ±(2% of reading + 3 digits)
2000mV/20V/200V: ±(2% of reading + 5 digits)
600V: ±(2.5% of reading + 5 digits)
AC Voltage:
200V/600V: ±(2% of reading + 10 digits)
Frequency Range: 45Hz to 450Hz
DC Current:
200uA/2000uA/20mA: ±(2% of reading + 2 digits)
200mA: ±(2.5% of reading + 2 digits)
10A: ±(2.5% of reading + 10 digits)
Resistance:
200Ω: ±(2.5% of reading + 10 digits)
2000Ω/20kΩ/200kΩ/2000kΩ: ±(2.5% of reading + 4 digits)
